Axles & Components 3 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. QUICK CONNECT LIPPERT AXLES ALWAYS TAKE YOU FURTHER Lippert axles always take you further. Our stateof-the-art robotic welders ensure the highest precision and quality on every component. Our axle assemblies and components are traceable down to the exact production run and original lot number, giving us optimum product visibility and serviceability. SPRING & TORSION TRAILER AXLES OVER 3,000 SPRING & TORSION AXLES MADE EVERY DAY Assembled in the USA Superior strength& quality Super lube system Proud to manufacture all of our custom hitches in the USA Verified using ultrasound technology to ensure proper weld location and penetration Time-saving lubrication system requires no disassembly of wheels or hubs WHENEVER, WHEREVER, WE MAKE YOUR EXPERIENCE BETTER.™ (M6V)
4 Axles & Components See manufacturer’s catalog for more applications. Specifications are subject to change without notice. AXLE SPEC SHEET Beam Only Axle Beam Round Diameter 2K = 1-34" 3.5K = 2-3/8" 3.5k = 3" Special Order 5.2-7K = 3" 8K = 3" or 3-1/2" DOM Call For Larger Axles Customer Part Number Customer Part Number Axle Type Brake Type Tube Diameter Bolt Pattern Brake Idler Stud Size Bolt Pattern Brake Idler Stud Size Wiring Requirements Special Instructions: : Brand if Necessary LCI Side mount Brackets Bracket Style Bracket Orientation Lug Nuts Axle Spec Sheet Angle Hub Face Dimension Angle position Wheel Options Spring Type A/P Kit requirements Spring Length Axle Spacing U-Bolt Kit Spring Pads Wiring Axle Type Tube Diameter Brkts dim. Camber Spring Center Dimension Spring Orientation Lug Nuts Camber Brake Flange Lubrication Type Hub Face Dimension Brake Type Lubrication Type Fluid Type Tube Type Fluid Type Tube Type Spindle Style Rubber Capacity Max. Capacity Spring Capacity Spring Axle Torsion Axle Model Model # 5.2K 2K 3.5K 6K 10K 9 8K 7K 12K 5.2K 2K 3.5K 6K 10K 8K 7K 9H 10 11 12 Straight Drop Standard Super Lube / Zirk Brake Idler Electric Disc Hydraulic Yes No Standard Heavy Wall Standard Super Lube / Zirk Brake Idler Disc Electric Disc Hydraulic Overslung Underslung Low Profile High Profile Yes No Yes No Yes No Yes No Upturn (-) Downturn (+) 22.5° 0° 10° 45° Inboard / STD Outboard / REV 550 545 655 865 Yes No 21" 24" 26" 1/2" 5/8" 9/16" Single Aluminum Double Eye Slipper 440 475 555 3/4" 1/2" 9/16" 3/4" Dual ____ 13 550 545 655 865 440 475 555 550 545 655 865 440 475 555 550 545 655 865 440 475 555 Oil Grease Oil Grease Square Std Diamond Standard Special Standard Special _____________ SBS / Neverlube SBS / Neverlube 25.25" 5/8" 7.2K Yes Yes No No Yes No OSB ISB Axle Specification Sheet (M6V)
Axles & Components 5 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. AXLE SPEC SHEET (M6V) LCI Part # Capacity Free length # of Leaves Dexter TRP UCF Standens Emco Axletek Eye To Eye Length Stacked Leaf Thickness Loaded Arch Height Stack Leaf Width 127094 1000 lbs 20.38 3 072-017-00 DE-7217 UNA-169 72-17 1020 ML-017-00 20 3/8 +/- 1/8 0.786 +/- .015 2.12 1.72 - 1.85 211712 1000 lbs 26 2 - - - - AWS-2 - 26 0.72 3.00 1.72 - 1.75 127103 1250 lbs 23.13 3 072-006-00 DE-726 UNA-135 72-6 72-6 ML-006-00 23 1/8 +/- 1/8 0.937 +/- .015 2.50 1.72 - 1.85 125228 1250 lbs 25.25 3 072-022-00 DE-7222 UNA-219 72-22 PR-722 ML-002-00 25 1/4 +/- 1/8 0.937 +/- .015 1.75 1.72 - 1.85 125269 1400 lbs 20.5 4 072-013-00 DE-7213 UNA-167 72-13 72-13 ML-013-00 20 1/2 +/- 1/8 1.106 +/- .020 2.38 1.72 - 1.85 125215 1750 lbs 23.13 3 072-009-00 DE-729 UNA-216 72-9 72-09 ML-009-00 23 1/8 +/- 1/8 1.080 +/- .015 2.50 1.72 - 1.85 124903 1750 lbs 25.25 4 072-042-00 DE-7242 / DESW48 UNA-212 72-42 PR-48 ML-042-00/ SW48 25 1/4 +/- 1/8 1.272 +/- .020 1.75 1.72 - 1.85 330903 1750 lbs 25.25 1 - - - - - PSU-042 25 5/8 +/- 1/8 0.700 +/- .018 1.75 1.750 + .03 / - .02 125797 2000 lbs 25.25 3 072-024-00 DE-7224 UNA-220 72-24 72-24 ML-024-00 / SW3 25 1/4 +/- 1/4 1.162 +/- .017 1.75 1.72 - 1.85 699453 2000 lbs 26 4 - - - - AWS-4 - 26 +/- 1/4 - - 1.72 - 1.85 129745 2000 lbs 25.25 4 072-078-00 - - 72-78 PR-4 ML-078-00 25 1/4 +/- 1/4 1.440 +/- .032 2.00 1.72 - 1.85 133982 2500 lbs 23.13 4 072-020-00 - UNA-79 72-20 72-20 ML-020-00 23 1/8 +/- 1/4 1.440 +/- .020 2.50 1.72 - 1.85 702095 2600 lbs 25.25 4 072-097-00 DE-7297 - 72-97 72-97/72-25R ML-097-00 25 1/4 +/- 1/4 1.522 +/- .022 1.75 1.72 - 1.85 7020951 2600 lbs 25.25 4 - 72-97/72-25R - 25 1/4 +/- 1/4 1.522 +/- .022 1.75 1.72 - 1.85 334743 2900 lbs 25.25 5 - SW5 or DE-1764 UNA-111 - SW5 or PR-5 MLA-111 25 1/4 +/- 1/4 - 1.75 1.72 - 1.85 702096 3000 lbs 25.13 4 - DE-7226LF - 72-26LF 72-26LF ML-026-LF 25 1/8 +/- 1/4 1.563 +/- .020 1.75 1.72 - 1.85 7020961 3000 lbs 25.13 4 - 72-26LF - 25 1/8 +/- 1/4 1.563 +/- .020 1.75 1.72 - 1.85 724357 3000 lbs 27 6 - DE-33617 - - PR-627 - 27 +/- 1/4 2.410 +/- .020 1.75 1.72 - 1.85 679372 3500 lbs 24.88 6 072-098-00 DE-7298 - 72-98 72-98/72-27R ML-098-00 24 7/8 +/- 1/4 2.049 +/-.030 1.75 1.72 - 1.85 6793721 3500 lbs 24.88 6 072-098-00 72-98/72-27R ML-098-00 24 7/8 +/- 1/4 2.049 +/-.030 1.75 1.72 - 1.85 679373 4000 lbs 24.88 7 072-100-00 DE-72100 - 72-100 72-100/72-79R ML-100-00 24 7/8 +/- 1/4 2.520 +/- .035 1.75 1.72 - 1.85 6793731 4000 lbs 24.88 7 072-100-00 72-100/72-79R ML-100-00 24 7/8 +/- 1/4 2.520 +/- .035 1.75 1.72 - 1.85 AXLE LEAF SPRINGS CROSSOVER CHART W/BRONZE BUSHINGS W/BRONZE BUSHINGS W/BRONZE BUSHINGS W/BRONZE BUSHINGS
6 Axles & Components See manufacturer’s catalog for more applications. Specifications are subject to change without notice. AXLE SPEC SHEET (M6V) LCI Part # Capacity Free length # of Leaves Dexter TRP UCF Standens Emco Axletek Eye To Eye Length Stacked Leaf Thickness Loaded Arch Height Stack Leaf Width 196770 400 lbs 25 Slip 2 WA‐2 ‐ ‐ ‐ WA‐2 ‐ 24.25 0.53 4.00 1.72 194616 700 lbs 27 Slip 2 072‐003‐00 ‐ UNA‐132 ‐ 72‐3 ‐ 27 0.582 5.25 1.72 ‐1.85 132819 1000 lbs 27 Slip 2 072‐002‐00 ‐ UNA‐133 72‐2 72‐2 ML‐002‐00 27 0.683 +/‐ .010 4.00 1.72 ‐ 1.85 230281 1250 lbs 25 Slip 4 ‐ ‐ ‐ ‐ BT25‐12 ‐ 25 1.048 2.25 1.75 157739 1750 lbs 25 Slip 3 ‐ ‐ ‐ ‐ BT25‐22 ‐ 25 1.08 2.50 1.72 ‐ 1.85 136527 2000 lbs 26.88 Slip 4 072‐030‐00 SH‐7230 UNA‐230 72‐30 803T3 ML‐030‐00 26.88 1.329 +/‐ .020 2.00 2 + .04 / ‐ .03 125250 2500 lbs 26.88 Slip 4 072‐031‐00 SH‐7231 UNA‐231 72‐31 1003T3 ML‐031‐00 26.88 1.440 +/‐ .020 2.00 2 + .04 / ‐ .03 342781 3500 lbs 26.5 Slip 5 ‐ SH‐E5226 ‐ ‐ E5226 ‐ 26.5 ‐ 2.50 2.00 710493 3500 lbs 26.88 Slip 5 72‐32HTL ‐ 26.88 1.89 +/‐ .025 2.00 2 +.04 / ‐ .03 797547 3500 lbs 26.5 Slip 6 ‐ HW5116 ‐ ‐ HW5116 ‐ 26.5 2.16 2.00 2.00 643611 4000 lbs 26.88 Slip 5 ‐ ‐ ‐ ‐ 72‐32‐ 9/16HDRB Rubber Bushed 26.88 1.974 2.00 2 +.04 / ‐ .03 710494 4000 lbs 26.88 Slip 7 72‐33HTL ‐ 26.88 2.61 2.00 2 +.04 / ‐ .03 334744 4000 lbs 29.5 Slip 6 ‐ SH‐E5115 ‐ ‐ E5115 ‐ 29.5 ‐ 2.50 2 + .04 / ‐ .03 796558 4000 lbs 26.5 Slip 7 ‐ SH‐E5226‐7 ‐ ‐ E5226‐7 ‐ 26.5 2.52 2.00 2 + .04 / ‐ .03 176326 5000 lbs 30.5 Slip 5 072‐080‐00 ‐ UNA‐298 72‐80 72‐80 Rubber Bushed 30.5 2.143 2.70" 2.50 296155 6000 lbs 30.5 Slip 6 072‐044‐00 ‐ UNA‐269 ‐ 72‐44 Rubber Bushed 30.5 2.406 2.74" 3.00" 676455 6250 lbs 32.5 Slip 6 ‐ ‐ ‐ ‐ 93182‐11A Rubber Bushed 32.5 2.75 2.85 2.5 353498 8000 lbs 30.5 Slip 6 ‐ SR‐7246 ‐ ‐ 72‐46 Rubber Bushed 30.5 2.682 2.74" 3.00" 771492 11,200 lbs 43.75 Slip 3 ‐ ‐ ‐ ‐ 354‐00 Dbl Slipper 43.75 2.46 5.25" 3.00" SLIPPER SPRINGS CROSSOVER CHART REPLACES 125203 REPLACES 156446
Axles & Components 7 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. AXLE SPEC SHEET (D6H) AXLE SPECIFICATION FORM THIS FORM IS TO BE USED FOR AXLE SPECIFICATION ONLY AND IS NOT TO BE USED TO E ENTER OR CONFIRM YOUR PURCHASE ORDER. KINDLY REFER TO CATALOG FOR ANY C CLARIFICATION OF SECTIONS AS REQUIRED. Customer Name ___________________________________ Telephone # _____________________ Address _______________________________________ City ____________________ State ______ THIS FORM IS TO BE USED FOR AXLE SPECIFICATION ONLY AND IS NOT TO BE USED TO E C CLARIFICATION OF SECTIONS AS REQUIRED. Customer Name ___________________________________ Telephone # _____________________ Address _______________________________________ City ____________________ State ______
8 Axles & Components See manufacturer’s catalog for more applications. Specifications are subject to change without notice. BRAKE ASSEMBLIES AND AXLE PARTS Electric brake assemblies Idler hub assemblies Brake hub assemblies Brake Assembly Replacements Parts • Easy, do-it-yourself installation • Left-hand (driver) and right-hand (passenger) • Four-, five- and seven-bolt mounting patterns • Hardware sold separately • Lippert genuine replacement part • Made from solid iron • All kits include #333948 bearing kit • Includes bearing cones, seal and grease installed • 1-year warranty • Lippert genuine replacement part • Made from solid iron • All kits include #333948 bearing kit • Includes bearing cones, seal and grease installed • 1-year warranty • Compatible with Lippert electric brake assemblies • Available for 10" x 2.25" or 12" x 2" assemblies • Compatible with most RV manufacturers • Magnet kit comes in oval design • Pads are fully bonded to shoes for long life and more braking torque BRAKE COMPONENTS Part # Capacity Bolt Pattern Stud Price (M6V) - 814198 2,200 lb. 5 on 4-1/2" 1/2" (M6V) - 814199 3,500 lb. 5 on 4-1/2" 1/2" (M6V) - 814196 2,200 lb. 5 on 4-1/2" 1/2" (M6V) - 814197 2,200 lb. 4 on 4" 1/2" Part # Capacity Bolt Pattern Stud Price (M6V) - 814200 3,500 lb. 5 on 4-1/2" 1/2" (M6V) - 141286 4,000 lb. 6 on 5-1/2" 1/2" (M6V) - 814202 5,200 to 6,000 lb. 6 on 5-1/2" 1/2" (M6V) - 814203 6,000 to 7,000 lb. 8 on 6-1/2" 1/2" (M6V) - 814204 6,000 to 7,000 lb. 8 on 6-1/2" 9/16" Part # Side Capacity Size Bolt Price (M6V) - 297956 LH 3,500 lb. 10" x 2.25" 4 (M6V) - 298274 RH (M6V) - 298275 LH 4,000 - 7,000 lb. 12" x 2" 5 (M6V) - 298276 RH (M6V) - 298277 LH 8,000 lb. 12.25" x 3.38" 4 (M6V) - 298279 RH Part # Side Capacity Size Bolt Price (M6V) - 181935 LH 10,000 lb. 12.25" x 3.38" 7 (M6V) - 181936 RH (M6V) - 297998 LH 12,000 - 16,000 lb. 12.25" x 5" 7 (M6V) - 2979981 RH (M6V) - 814197 (M6V) - 297956 (M6V) - 298277 (M6V) - 814200 (M6V) - 136454 (10" x 2.25") (M6V) - 136451 (10" x 2.25") (M6V) - 136447 (12" x 2") (M6V) - 136444 (12" x 2") (M6V) - 136453 (adjuster & spring) (M6V)
Axles & Components 9 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. BRAKE ASSEMBLIES AND AXLE PARTS (M6V) BRAKE ASSEMBLIES AND AXLE PARTS (M6V) - 121101 (M6V) - 121097 (M6V) - 121098 (M6V) - 121099 (M6V) - 121100 (M6V) - 128877 (M6V) - 137383 Part No. Springs Capacity Load length Eye-to-eye length Loaded arch length Standens (M6V) - 127094 3 1,000 lb. 21" 20.375" 2.12" 72-17 (M6V) - 127103 3 1,250 lb. 24" 23.125" 2.5" 72-06 (M6V) - 125269 4 1,400 lb. 21" 20.5" 2.38" 72-13 (M6V) - 125215 3 1,750 lb. 24" 23.2" 2.5" 72-09 (M6V) - 124903 4 1,750 lb. 26" 25.25" 1.5" 72-42 (M6V) - 125799 4 2,000 lb. 24" 23.125" 2.5" 72-18 (M6V) - 125797 3 2,000 lb. 26" 25.25" 1.75" 72-24 (M6V) - 129745 4 2,200 lb. 26" 25.25" 2" 72-78 (M6V) - 133982 4 2,500 lb. 24" 23.125" 2.5" 72-20 (M6V) - 702096 4 3,000 lb. 26" 25.25" 1.75" 72-26 (M6V) - 679372 6 3,500 lb. 26" 24.875" 1.75" 72-27 (M6V) - 679373 7 4,000 lb. 26" 24.875" 1.75" 72-79 (M6V) - 702095 4 2,600 lb. 26" 25.25" 1.75" 72-97 Part No. Springs Capacity Load length Eye-to-eye length Loaded arch length Standens (M6V) - 132819 2 1,000 lb. 25" 24.75" 4" 72-2 (M6V) - 136527 4 2,000 lb. 25" 26.5" 2" 72-30 (M6V) - 125250 4 2,500 lb. 25" 26.5" 2" 72-31 (M6V) - 710493 5 3,500 lb. 27.875" 26.875" 2" 72-32 (M6V) - 125203 5 3,500 lb. 27.5" 26.5" 2" 72-33 (M6V) - 176326 5 5,000 lb. 30" 30" 2.7" 72-80 AXLE SPRINGS AND ATTACHING PARTS Leaf springs Slipper springs Attaching part kits Part No. Springs (M6V) - 121101 Single Axle AP Kit; 3-1/8" Link (M6V) - 121097 Tandem AP Kit; 33" Axle Spacing; EQ-104 (M6V) - 121098 Tandem AP Kit; 33" Axle Spacing; EQ-310 (M6V) - 121099 Tandem AP Kit; 35" Axle Spacing; EQ-E1 (M6V) - 121100 Triple AP Kit; 33" Axle Spacing; EQ-104 & 105 (M6V) - 128877 Tandem Slipper AP Kit; 33.5" Axle Spacing; EQ-1304 (M6V) - 137383 Triple Slipper AP Kit; 33.5" Axle Spacing; EQ-1304
10 Axles & Components See manufacturer’s catalog for more applications. Specifications are subject to change without notice. BRAKE ASSEMBLIES AND AXLE PARTS A B All cast equalizers come with nylon bushings Spindle Washers Shackle Link Assemblies Axle Bolts (M6V) - 119216 (M6V) - 119215 (M6V) - 119214 (M6V) - 122106 (M6V) - 126741 (M6V) - 126277 (M6V) - 126460 A B A B A B (M6V) - 125675 (M6V) - 1567651 (M6V) - 126172 (M6V) - 133207 (M6V) - 122487 (M6V) - 133485 Note - shackle link dimensions are measured from center of hole to center of hole (M6V) - 271254 (M6V) - 121803 (M6V) - 122102 EQUALIZERS, SPINDLE WASHERS, U-BOLTS, SHACKLE LINKS, AND AXLE BOLTS Equalizers Yellow Zinc U-Bolts Shackle Links (M6V) - 126197 (M6V) - 126238 BRAKE ASSEMBLIES AND AXLE PARTS Part No. Type A B Hole Diameter (M6V) - 122106 EQ-E1 7-3/4" 2-7/8" 9/16" (M6V) - 126277 EQ-105 6-3/4" 2" 9/16" (M6V) - 126460 EQ-104 5-3/4" 2" 9/16" (M6V) - 126741 EQ-310 6-1/16" 4" 9/16" Part No. Description (M6V) - 125675 Standard 2.25" Shackle Link Assembly (M6V) - 133485 Standard 3.13" Shackle Link Assembly Part No. Description (M6V) - 119214 1" Round Spindle Washers (M6V) - 119215 1" D-Flat Spindle Washer (M6V) - 119216 1" Tang Spindle Washer Part No. Description (M6V) - 139737 U-Bolt 3/8"-24 x 4" for 1.75" Axle Tube (M6V) - 122073 U-Bolt 1/2"-20 x 5.1" for 2.38" Axle Tube (M6V) - 122070 U-Bolt 1/2"-20 x 6.5" for 3" Axle Tube Part No. Description (M6V) - 122487 Standard 2.25" Shackle Link (M6V) - 133207 Standard 3.13" Shackle Link (M6V) - 126172 Heavy-Duty 2.25" Shackle Link (M6V) - 1567651 Heavy-Duty 3.13" Shackle Link Part No. Description (M6V) - 121803 Press-In Wheel Stud; 1/2"-20 UNF x 1.98", 0.617" Knurl (M6V) - 122102 Shoulder Bolt; 9/16" x 2.32" w/ 7/16"-20 Thread (M6V) - 271254 Shoulder Bolt; 9/16" x 2.82" w/ 7/16"-20 Thread (M6V) - 126238 Wet Bolt; 9/16" x 3.24" w/ 7/16"-20 Thread (M6V) - 126197 Wet Bolt; 9/16" x 3.74" w/ 7/16"-20 Thread (M6V)
Axles & Components 11 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. BRAKE ASSEMBLIES AND AXLE PARTS (M6V) (M6V) - 106181 (M6V) - 106182 (M6V) - 106183 (M6V) - 106185 (M6V) - 106184 (M6V) - 102906 Boot Hanger Side View A A A B C D D (M6V) - 297429 (M6V) - 297427 (M6V) - 297426 (M6V) - 122103 (M6V) - 122077 (M6V) - 122085 (M6V) - 134581 (M6V) - 122079 (M6V) - 122076 (M6V) - 122081 Standard stud size is 9/16" Axle Nuts Dust Caps & Miscellaneous Parts (M6V) - 122075 (M6V) - 122084 (M6V) - 126171 (M6V) - 122255 (M6V) - 122064 (M6V) - 122099 (M6V) - 122067 (M6V) - 122071 (M6V) - 127206 (M6V) - 127300 (M6V) - 122065 AXLE HANGERS, HARDWARE, DUST CAPS AND MISC. PARTS Axle Mounting Kits (mounts one axle) Axle Hangers BRAKE ASSEMBLIES AND AXLE PARTS Part No. Description (M6V) - 297426 Axle Mounting Kit; 1.75" Axle Tube 3/8"-24 x 4" U-Bolts (M6V) - 297427 Axle Mounting Kit; 2.375" Axle Tube 1/2"-20 x 5" U-Bolts (M6V) - 297429 Axle Mounting Kit; 3.0" Axle Tube 1/2"-20 x 7.25" U-Bolts Part No. Description (M6V) - 122103 Shackle Bolt Nut; 7/16"-20 (M6V) - 122081 6-Slot Castle Spindle Nut; 1"-14 (M6V) - 122076 60˚ Cone Lug Nut; 1/2"-20 (M6V) - 122079 U-Bolt Flange Nut; 1/2"-20 (M6V) - 122077 Self-Locking Brake Nut; 3/8"-24 (M6V) - 122085 Brake Hex Nut; 7/16"-20 (M6V) - 134581 60˚ Cone Lug Nut; 9/16"-18 Part No. Description (M6V) - 122099 Dust Cap; Non-Lubed for 2K & 3.5K; DC 200 (M6V) - 122067 Dust Cap; Lubed for 2K & 3.5K; DC 200L (M6V) - 122071 Dust Cap; Non-Lubed for 5.2K & 6K; DC 250 (M6V) - 122064 Dust Cap; Lubed for 5.2K & 6K; DC 250L (M6V) - 127206 Dust Cap; Non-Lubed for 7K & 8K; DC 275 (M6V) - 127300 Dust Cap; Lubed for 7K & 8K; DC 275L (M6V) - 122065 Universal Rubber Dust Cap Plug (M6V) - 122075 Standard Cotter Pin for LCI Axle Assemblies (M6V) - 122084 3M Sealed Wire Connector (M6V) - 126171 Bronze Bushing, .58ID x .7000 x 1.74 (M6V) - 122255 Grease Zerk for Super Lube Axles up to 8K Part No. Desc. A B C D (M6V) - 106181 1.25" Axle Hanger 1.25" 1.86" 2" 9/16" (M6V) - 106182 2.25" Axle Hanger 2.14" 2.87" 2" 9/16" (M6V) - 106183 3.25" Axle Hanger 3.13" 3.87" 2" 9/16" (M6V) - 106185 4.25" Axle Hanger 4.05" 4.75" 2" 9/16" (M6V) - 106184 5" Axle Hanger 4.82" 5.55" 2" 9/16" (M6V) - 102906 3" & 5" Boot Hanger 3 & 5" 5.75" 2" 9/16"
12 Axles & Components See manufacturer’s catalog for more applications. Specifications are subject to change without notice. BRAKE ASSEMBLIES AND AXLE PARTS Axle Leaf Springs Shackle Link Hangers (A1W) - 014125269 (A1W) - 0141261714 Part No. Description (A1W) - 014127094 Axle Leaf Springs 1,000 lbs., 3 leaves, 20-3/8” +/- 1/8” eye to eye length, 0.786” +/- .015” stacked leaf thickness, 2.12” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 014127103 Axle Leaf Springs 1,250 lbs., 3 leaves, 23-1/8” +/- 1/8” eye to eye length, 0.937” +/- .015” stacked leaf thickness, 2.50” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 014125269 Axle Leaf Springs 1,400 lbs., 4 leaves, 20-1/2” +/- 1/8” eye to eye length, 1.106” +/- .020” stacked leaf thickness, 2.38” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 014125215 Axle Leaf Springs 1,750 lbs., 3 leaves, 23-1/8” +/- 1/8” eye to eye length, 1.080” +/- .015” stacked leaf thickness, 2.50” loaded arch height, 1.72”-1.85” Stack leaf width (A1W) - 014124903 Axle Leaf Springs 1,750 lbs., 4 leaves, 25-1/4” +/- 1/8” eye to eye length, 1.272” +/- .020” stacked leaf thickness, 1.50” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 014125799 Axle Leaf Springs 2,000 lbs., 4 leaves, 23-1/8” +/- 1/8” eye to eye length, 1.366” +/- .020” stacked leaf thickness, 2.50” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 014125797 Axle Leaf Springs 2,000 lbs., 3 leaves, 25-1/4” +/- 1/8” eye to eye length, 1.162” +/- .017” stacked leaf thickness, 1.75” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 014133982 Axle Leaf Springs 2,500 lbs., 4 leaves, 23-1/8” +/- 1/8” eye to eye length, 1.440” +/- .020” stacked leaf thickness, 2.50” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 014122111 Axle Leaf Springs 3,000 lbs., 4 Or 5 leaves, 25-1/4” +/- 1/8” eye to eye length, 1.563” +/- .020” stacked leaf thickness, 1.75” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 014122113 Axle Leaf Springs 3,500 lbs., 6 leaves, 24-7/8” +/- 1/8” eye to eye length, 2.049” +/- .030” stacked leaf thickness, 1.75” loaded arch height, 1.72”-1.85” stack leaf width (A1W) - 0141261714 4 pack spring bushing - bronze (A1W) - 014126282 Spring bushing - nylon (A1W) - 014125250 Slipper Spring 2,500 lbs., 4 leaves, eye to eye 26.5” (A1W) - 014125203 Slipper Spring 3,500 lbs., 5 leaves, eye to eye 26.5” Measure center of hole to center of hole. Order second link plate and nuts separately. (A1W) - 014122487 (A1W) - 014125675 (A1W) - 014133485 (A1W) - 014122102 (A1W) - 014106182 (A1W) - 014106184 (A1W) - 014102906 A C B D Part No. Description (A1W) - 014122487 2-1/4” Shackle Link with yellow zinc (A1W) - 014125675 2-1/4” Shackle Link / bolt assembly (A1W) - 014133207 3-1/8” Shackle Link, silver zinc (A1W) - 014133485 3-1/8” Shackle Link / bolt assembly (A1W) - 014122103 7/16” x 20 Flanged Hex Lock Nut, zinc (A1W) - 014122102 2.32 x 9/16” with 7/16” - 20 threaded shoulder bolt, black phosphorus coated Part No. Description A B C D (A1W) - 014106183 3.25 Axle Hanger 3.95” 2” 3” 9/16” (A1W) - 014106182 2.25” Axle Hanger 2.95” 2” 3” 9/16” (A1W) - 014106181 1.25” Axle Hanger 1.95” 2” 3” 9/16” (A1W) - 014106185 4.25” Axle Hanger 4.82” 2” 3” 9/16” (A1W) - 014106184 5” Axle Hanger 5.62” 2” 3” 9/16” (A1W) - 014102906 Boot Hanger, 3” and 5” 5.775” 2” 5” 9/16” (A1W)
Axles & Components 13 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. BRAKE ASSEMBLIES AND AXLE PARTS (A1W) Spindles Washers And Nuts Tie Plates, Shock Kits, And U-Bolts Equalizers Part No. Description (A1W) - 014142161 2,200 lbs. Sprung Axle Spindle - Straight, Flg, Lube, 1.75” (A1W) - 014142162 2,200 lbs. Sprung Axle Spindle - Straight, No Flg, Lube, 1.75” (A1W) - 014123383 2,800 - 3,500 lbs. Sprung Axle Spindle - Straight, Flg, Lube, 2.38” (A1W) - 014134563 2,800 - 3,500 lbs. Sprung Axle Spindle - Straight, Flg, Lube, 3” (A1W) - 014123384 2,800 - 3,500 lbs. Sprung Axle Spindle - Drop, Flg, Lube, 2.38” (A1W) - 014140695 2,800 - 3,500 lbs. Sprung Axle Spindle - Drop, Flg, Lube, 3” (A1W) - 014122455 4,000 - 7,000 lbs. Sprung Axle Spindle - Straight, Flg, Lube, 3” (A1W) - 014122456 4,000 - 7,000 lbs. Sprung Axle Spindle - Drop, Flg, Lube, 3” (A1W) - 014122081 6 Slot Spindle Nut, 1” - 14 UNS (A1W) - 014119335 2pk Spindle Nuts and Washers, 1” D-Flat and Tang Washers, 6 Slot Nut Part No. A B C D E F H (A1W) - 014142161 1.31" 1.63" 6.7" 1.5" 1.062" 1.062" 1.75" (A1W) - 014142162 1.31" NA 5.61" 1.5" 1.062" 1.062" 1.75" (A1W) - 014123383 2" 2.26" 6.23" 1.72" 1.376" 1.062" 2.44" (A1W) - 014134563 2.55" 2.26" 6.23" 1.72" 1.376" 1.062" 3" (A1W) - 014123384 2" 2.26" 8.13" 1.72" 1.376" 1.062" 2.44" (A1W) - 014140695 2.55" 2.26" 8.13" 1.72" 1.376" 1.062" 3" (A1W) - 014122455 2.46" 2.75" 8.13" 2.25" 1.749" 1.249" 3" (A1W) - 014122456 2.46" 2.75" 9.89" 2.25" 1.749" 1.249" 3" Part No. Description (A1W) - 014139737 U-Bolt 3/8” - 24 x 4.00” for 1.75” Tube, YZ (A1W) - 014122073 U-Bolt 1/2” - 20 x 5.10” for 2.38” Tube, YZ (A1W) - 014122070 U-Bolt 1/2” - 20 x 6.50” for 3.00” Tube, YZ (A1W) - 014132049 U-Bolt 1/2” - 20 x 7.25” for 3.00” Tube, YZ (A1W) - 014139874 1.75” Tie Down Plate uses 3/8” U-Bolts (A1W) - 014133766 2.375” Tie Down Plate for 2” Spring (A1W) - 014122226 3” Zinc Tie Down Plate(2” Slipper Spring) Zinc (A1W) - 014146677 Over/Under Conversion Kit for 23⁄8” Tube (A1W) - 014162753 Over/Under Conversion Kit for 3” Tube (A1W) - 014156018 Shock Kit w/Tie Plates For 23⁄8” and 3” Tube (A1W) - 014122108 Shock Kit with Hardware (A1W) - 014119215 (A1W) - 014119214 (A1W) - 014119216 (A1W) - 014126741 (A1W) - 014122106 (A1W) - 014156018 (A1W) - 014126277 Part No. Description (A1W) - 014119215 1” D-Flat Spindle Washer (A1W) - 014119214 1” Round Spindle Washer (A1W) - 014119216 Tang Washer (A1W) - 12207510 10pk Cotter Pin 1/8” x 1.75” (A1W) - 014122103 7/16” x 20 Flanged Hex Lock Nut, Zinc (A1W) - 014122081 6 Slot Spindle Nut, 1” - 14 UNS (A1W) - 014122079 1/2” x 20 Zinc Coated Flange Nut (A1W) - 014122077 3/8” - 24 Self-Locking Keps Nut Part No. Description (A1W) - 014122085 7/16” - 20 Hex Nut Zinc Plated (A1W) - 014122076 1/2” - 20, 60-Degree Cone Wheel Nut (A1W) - 014127146 1/2” - 20 UNF 2B Cap Nut (A1W) - 014134581 9/16” - 18, 60-Degree Wheel Nut (A1W) - 014119335 2pk Spindle Nuts and Washers, 1” D-Flat and Tang Washers, 6-Slot Nut Part No. Description A B C D (A1W) - 014122106 EQ-E1 Assembly 7.75” 9/16” 9/16” 2.88” (A1W) - 014126277 EQ-105 Assembly 6.75” 9/16” 9/16” 2” (A1W) - 014126460 EQ-104 Assembly 5.75” 9/16” 9/16” 2” (A1W) - 014126741 EQ-310 Assembly 6.13” 9/16” 9/16” 4” (A1W) - 014127467 EQ-356 Assembly 6.13” 9/16” 9/16” 2.50” A B C D E F H C A D B E F H C A D B All Equalizers include nylon bushings Shock and mounting hardware to install shock to axle’s suspension. Axle must have appropriate tie plate and frame mount to bolt shock to. Direct OEM replacement for many popular trailers. Dimensions: Overall 18.00” extended, 15.81” nominal, 13.62” compressed, Body 7.50”: compressed +/-.12” (4.50” travel), 12.00” extended +/-.12” (3.38” dead length). (A1W) - 014142161 (A1W) - 014122455 (A1W) - 014134563 (A1W) - 014122108 (A1W) - 014162753 (A1W) - 014122070
14 Axles & Components See manufacturer’s catalog for more applications. Specifications are subject to change without notice. BRAKE ASSEMBLIES AND AXLE PARTS Part No. Description (A1W) - 014121101 Single Axle A/P Kit with 3-1/8" Link (A1W) - 014121097 15" Tandem A/P Kit for 33" Axle spacing EQ-104 (A1W) - 014121098 15" Tandem A/P Kit for 33" Axle spacing 4" tall EQ-310 (A1W) - 014121099 16" Tandem A/P Kit for 35" Axle spacing EQ-E1 (A1W) - 014121100 Triple A/P Kit for 33" Axle spacing EQ-104 and EQ-105 (A1W) - 014128877 Tandem Slipper A/P Kit for 33.5" Axle spacing, with EQ 13-4 (A1W) - 014137383 Triple Slipper A/P Kit for 33.5" Axle spacing, with EQ 13-4 (A1W) - 014146220 Triple A/P Kit for 35” Axle spacing EQ-104 with wet bolt Part No. Description (A1W) - 014122099 Grease Cap, Non lubed for 2k and 3.5k, DC200, 1.990" (A1W) - 014122067 Grease Cap with rubber plug, Lubed for 2k and 3.5k, DC200L, 1.990" (A1W) - 014122071 Grease Cap, Non Lubed, 5.2k and 6k, DC250, 2.450" (A1W) - 014122064 Grease Cap with rubber plug, Lubed for 5.2k and 6k, (A1W) - 014127300 Grease Cap, Lubed for 7k and 8k, DC275L, 2.71" (A1W) - 014127206 Grease Cap, Non Lubed 7k and 8k, DC275, 2.7520" (A1W) - 0141220655 5pk Universal Rubber LBD Dust Plug Part No. Description (A1W) - 014121803 1⁄2-20 UNF x 1.84”, 0.617 KNURL, Press in Stud (A1W) - 014122290 2.32” x 9⁄16” Shackle Bolt with Nut (A1W) - 014122076 1/2” - 20, 60° Cone Wheel Nut (A1W) - 014127146 1/2” - 20 UNF 2B Cap Nut (A1W) - 014132592 9/16” - 18 Cap Lug Nut (A1W) - 014134581 9/16” - 18 60° Wheel Nut A/P Kits Grease Caps Wheel Studs And Nuts Bearing Kit (A1W) - 014121803 (A1W) - 014122290 (A1W) - 014121098 (A1W) - 014121099 (A1W) - 014121100 (A1W) - 014128877 (A1W) - 014137383 Inner Bearing Grease Seal Outer Bearing (A1W) - 122099 (A1W) - 122067 (A1W) - 127206 Part No. Description (A1W) - 0141250 Bearing Kit for 1,250 lb. with 1” Spindle (L-44643, L-44643, L-44610, L-44610, Seal and Pin) (A1W) - 0143500 Bearing Kit for 3,500 lb. Axle (L-44649, L-68149, L68111, L-44610, Seal and Pin) (A1W) - 0145200 Bearing Kit for 5,200 lb. Axle, (LM-67048, 25520, LM-67010, 25580, Seal and Pin) (A1W) - 0146000 Bearing Kit for 6,000 lb. Axle, (25580, 15123, 25520, 15245, Seal and Pin) (A1W) - 0147000 Bearing Kit for 7,000 lb. Axle, (25580, 25520, 14125A, 14276, Seal and Pin) (A1W) - 014035122 Bearing Kit for 3,500 lb. Axle (L-44649, L-68149, L68111, L-44610, Lug Nuts, Rubber Plug, Seal and Pin) (A1W) - 014052122 Bearing Kit for 5,200 lb. Axle, (LM-67048, 25520, LM-67010, 25580, Lug Nuts, Rubber Plug, Seal and Pin) (A1W) - 014060122 Bearing Kit for 6,000 lb. Axle, (25580, 15123, 25520, 15245, Lug Nuts, Rubber Plug, Seal and Pin) (A1W) - 014070122 Bearing Kit for 7,000 lb. Axle, (25580, 25520, 14125A, 14276, Lug Nuts, Rubber Plug, Seal and Pin) (A1W) - 0141220872 Double Lip Grease Seal for 2800-3500, 1.72” ID x 2.565” OD - 2pk. (A1W) - 0141395142 Double Lip Grease Seal for 2200, 1.502” ID x 1.987” OD - 2pk. (A1W) - 0141242878 8pk, Inner Cup, 25520, O.D. 3.265 (A1W) - 12429213 13pk, Outer Cup, LM-67010, O.D. 2.328 (A1W) - 12429613 13pk, Inner Cup, L-68111, O.D. 2.362 (A1W) - 12510215 15pk, Outer Cup, L-44610, O.D. 1.98 (A1W) - 12699611 11pk, Outer Cup, 15245, O.D. 2.441 (A1W) - 12701210 10pk, Outer Cup, 14276, O.D. 2.717 (A1W) - 18162810 10pk, Inner/Outer Bearing, L-44643, I.D. 1” (A1W) - 12208910 10pk, Outer Bearing, L-44649, I.D. 1.063 (A1W) - 0141220929 9pk, Inner Bearing, L-68149, I.D. 1.378 (A1W) - 0141220667 7pk, Inner Bearing, 25580, I.D. 1.75 (A1W) - 0141220909 9pk, Outer Bearing, LM-67048, I.D. 1.25 (A1W) - 0141220918 8pk, Outer Bearing, 15123, I.D. 1.25 (A1W) - 0141270098 8pk, Outer Bearing, 14125A, I.D. 1.25 (A1W) - 12208810 10pk, Seal for 5200/6000/7000, I.D. 2.25 (A1W) - 12208710 10pk, Seal for 3500 lb., I.D. 1.719 (A1W) - 18162110 10pk, Seal 1250 lb. with 1” Spindle, I.D. 1.249 (A1W) - 0141242872 2pk, Inner Cup, 25520, O.D. 3.265 (A1W) - 0141242922 2pk, Outer Cup, LM-67010, O.D. 2.328 (A1W) - 0141242962 2pk, Inner Cup, L-68111, O.D. 2.362 (A1W) - 0141251022 2pk, Outer Cup, L-44610, O.D. 1.98 (A1W) - 0141269962 2pk, Outer Cup, 15245, O.D. 2.441 (A1W) - 0141270122 2pk, Outer Cup, 14276, O.D. 2.717 (A1W) - 0141816282 2pk, Inner/Outer Bearing, L-44643, I.D. 1” (A1W) - 0141220892 2pk, Outer Bearing, L-44649, I.D. 1.063 (A1W) - 0141220922 2pk, Inner Bearing, L-68149, I.D. 1.378 (A1W) - 0141220662 2pk, Inner Bearing, 25580, I.D. 1.75 (A1W) - 0141220902 2pk, Outer Bearing, LM-67048, I.D. 1.25 (A1W) - 0141220912 2pk, Outer Bearing, 15123, I.D. 1.25 (A1W) - 0141270092 2pk,Outer Bearing, 14125A, I.D. 1.25 (A1W) - 0141220882 2pk,Seal for 5200/6000/7000, I.D. 2.25 (A1W) - 0141220872 2pk,Seal for 3500 lb., I.D. 1.719 (A1W) - 0141816212 2pk,Seal 1250 lb. with 1” Spindle, I.D. 1.249 (A1W) - 0141300352 3pk, Double Lip Seal, O.D. 3.376 Brake Components (A1W)
Brake Assemblies 15 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. WHEEL BEARING PROTECTORS (T1M) ©2021 Horizon Global MKG3835 RevA 5/19 BEARING PROTECTORS • Protects wheel bearings from the elements during all trailer operations • Automatically maintains the correct internal pressure – cannot damage seals • Chrome-plated steel construction • Sold in pairs and are available in bulk or full color display packages • Some models include vinyl cover (see chart) Part Number Description Hub Diameter (in.) (T1M) - BPC1980604 Bearing Protector with Covers 1.980 (T1M) - BP198S0304 Bearing Protector 1.980 (T1M) - BP244S0304 Bearing Protector 2.441 (T1M) - BP244S0604 Bearing Protector 2.4411 (T1M) - BB19800112 Bearing Protector Covers, (2 Pack) 1.980 (T1M) - BPC1980604 D A C B C A D B 1500 Series 1600 Series A = Flange Diameter (OD) B = Crown Height C = Flange Length D = Overall Height GREASE CAPS Part Number Mat. Guage A - Flange Diameter (in.) B - Crown Height (in.) C - Flange Length (in.) D - Overall Height (in.) 1500 Series (T1M) - 001501* 22 1.786 0.630 0.270 0.890 (T1M) - 001503* 22 1.786 1.160 0.375 1.535 (T1M) - 001523 20 1.943 0.690 0.310 1.000 (T1M) - 001524 20 1.943 1.040 0.340 1.380 (T1M) - 001505* 22 1.968 0.780 0.375 1.156 (T1M) - 001521 20 1.988 0.750 0.220 1.030 (T1M) - 001520* 22 2.446 1.030 0.313 1.340 (T1M) - 001515* 20 2.567 1.080 0.281 1.360 (T1M) - 001526 20 2.722 1.130 0.312 1.440 (T1M) - 001531 16 3.155 1.430 0.370 1.800 1600 Series (T1M) - 100235* 16 2.333 0.840 0.370 1.210 (T1M) - 001601 16 2.333 0.910 0.370 1.281 (T1M) - 001604 16 2.446 0.880 0.280 1.160 (T1M) - 001605 16 2.722 1.030 0.310 1.340 (T1M) - 001609 16 3.125 1.010 0.296 1.310 (T1M) - 001607 16 3.155 1.160 0.218 1.375 (T1M) - 001602 16 3.255 0.610 0.530 1.145 *Zinc plated for corrosion resistance
16 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. ELECTRIC BRAKES Brake Assemblies (D6G) Part No. Measurements Capacity Brake Type (D6G) - 023-026-00 10 X 2-1/4” 3,500 lbs. Electric Brake, Left Hand (D6G) - 023-027-00 10 X 2-1/4” 3,500 lbs. Electric Brake, Right Hand (D6G) - 023-105-00 12 x 2” 6,000 lbs. Electricectric Brake, Left Hand (D6G) - 023-106-00 12 x 2” 6,000 lbs. Electricectric Brake, Right Hand (D6G) - 023-180-00 12 x 2” 7,000 lbs. Electricectric Brake, Left Hand (D6G) - 023-181-00 12 x 2” 7,000 lbs. Electricectric Brake, Right Hand
Brake Assemblies 17 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. ELECTRIC BRAKES (D6G)
18 Brake Assemblies See manufacturer’s catalog for more applications. Specifications are subject to change without notice. ELECTRIC BRAKES Electric brake assemblies Idler hub assemblies Brake hub assemblies Brake Assembly Replacements Parts • Easy, do-it-yourself installation • Left-hand (driver) and right-hand (passenger) • Four-, five- and seven-bolt mounting patterns • Hardware sold separately • Lippert genuine replacement part • Made from solid iron • All kits include #333948 bearing kit • Includes bearing cones, seal and grease installed • 1-year warranty • Lippert genuine replacement part • Made from solid iron • All kits include #333948 bearing kit • Includes bearing cones, seal and grease installed • 1-year warranty • Compatible with Lippert electric brake assemblies • Available for 10" x 2.25" or 12" x 2" assemblies • Compatible with most RV manufacturers • Magnet kit comes in oval design • Pads are fully bonded to shoes for long life and more braking torque BRAKE COMPONENTS Part # Mfg # Capacity Bolt Pattern Stud (M6V) - 62-3003 814198 2,200 lb. 5 on 4-1/2" 1/2" (M6V) - 62-3004 814199 3,500 lb. 5 on 4-1/2" 1/2" (M6V) - 62-3001 814196 2,200 lb. 5 on 4-1/2" 1/2" (M6V) - 62-3002 814197 2,200 lb. 4 on 4" 1/2" Part # Mfg # Capacity Bolt Pattern Stud (M6V) - 62-3005 814200 3,500 lb. 5 on 4-1/2" 1/2" (M6V) - 71-5526 141286 4,000 lb. 6 on 5-1/2" 1/2" (M6V) - 62-3006 814202 5,200 to 6,000 lb. 6 on 5-1/2" 1/2" (M6V) - 62-3007 814203 6,000 to 7,000 lb. 8 on 6-1/2" 1/2" (M6V) - 62-3008 814204 6,000 to 7,000 lb. 8 on 6-1/2" 9/16" Part # Mfg # Side Capacity Size Bolt (M6V) - 48-4548 297956 LH 3,500 lb. 10" x 2.25" 4 (M6V) - 48-4549 298274 RH (M6V) - 48-4550 298275 LH 4,000 - 7,000 lb. 12" x 2" 5 (M6V) - 48-4551 298276 RH Part # Mfg # Side Capacity Size Bolt (M6V) - 48-4552 298277 LH 8,000 lb. 12.25" x 3.38" 4 (M6V) - 48-4553 298279 RH (M6V) - 62-0929 181935 LH 10,000 lb. 12.25" x 3.38" 7 (M6V) - 62-0930 181936 RH (M6V) - 62-0995 297998 LH 12,000 - 16,000 lb. 12.25" x 5" 7 (M6V) - 62-0996 2979981 RH (M6V) - 814197 (M6V) - 297956 (M6V) - 298277 (M6V) - 814200 (M6V) - 136454 (10" x 2.25") (M6V) - 136451 (10" x 2.25") (M6V) - 136447 (12" x 2") (M6V) - 136444 (12" x 2") (M6V) - 136453 (adjuster & spring) (M6V)
19 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. ELECTRIC BRAKES Brake Assemblies (HUS) ELECTRIC BRAKE ASSEMBLY 10" x 2.25", 4,400 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 32559 Complete Brake Assembly LH, Standard Wire (Red) (shown at right) (HUS) - 32560 Complete Brake Assembly RH, Standard Wire (Red) SELF-ADJUSTING ELECTRIC BRAKE ASSEMBLIES 10" x 2.25", 3,500 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 32288 Complete Brake Assembly LH (HUS) - 32289 Complete Brake Assembly RH 10" x 2.25", 4,400 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 32561 Complete Brake Assembly LH, Standard Wire (Red) (shown at right) (HUS) - 32562 Complete Brake Assembly RH, Standard Wire (Red) (shown at right) 12" x 2", 6,000 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 32292 Complete Brake Assembly LH (HUS) - 32293 Complete Brake Assembly RH 12" x 2", 7,000 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 32290 Complete Brake Assembly LH (HUS) - 32291 Complete Brake Assembly RH CSA Compliant HUSKY® SELF-ADJUSTING ELECTRIC BRAKE ASSEMBLIES FOR AXLE TEK OR DEXTER Complete assembly. Fits or replaces Axle Tek or Dexter. All assemblies are individually boxed. HUSKY® ELECTRIC BRAKE ASSEMBLY FOR AXLE TEK OR DEXTER Complete assembly. Fits or replaces Axle Tek or Dexter. All assemblies are individually boxed. (HUS) - 32559 (HUS) - 32561 (HUS) - 32562 RUGGED IS STANDARD EQUIPMENT.™
20 Brake Assemblies See manufacturer’s catalog for more applications. Specifications are subject to change without notice. ELECTRIC BRAKES RUGGED IS STANDARD EQUIPMENT.™ ELECTRIC BRAKE ASSEMBLY 12.25" x 3.375", 4-Bolt, 8,000 lb Axle Capacity PART# DESCRIPTION (HUS) - 33074 Complete Brake Assembly LH, Standard Wire (Red) (shown at left) (HUS) - 33075 Complete Brake Assembly RH, Standard Wire (Red) (HUS) - 33095 Bulk, Brake Assembly (HUS) - 33096 Bulk, Brake Assembly RH HUSKY® GENERAL DUTY SELF-ADJUSTING ELECTRIC BRAKE ASSEMBLIES FOR AXLE TEK OR DEXTER Complete assembly. Fits or replaces Axle Tek or Dexter. All assemblies are individually boxed. HUSKY® ELECTRIC BRAKE ASSEMBLY FOR AXLE TEK OR DEXTER • Automotive-grade friction material molded to brake shoes • Pads are fully bonded to shoes for long life and more braking torque • Less chance of cracking and crumbling that can lead to mechanical lockup, thanks to tapered edge and circular grinding • E-coated backing plate resists wear and corrosion Complete assembly. Fits or replaces Axle Tek or Dexter. All assemblies are individually boxed. (HUS) - 33074 (HUS) - 33076 (HUS) - 33077 SELF-ADJUSTING ELECTRIC BRAKE ASSEMBLIES 12.25" x 3.375", 7-Bolt, 10,000 lb Axle Capacity PART# DESCRIPTION (HUS) - 33076 Complete Brake Assembly LH, Standard Wire (Red) (shown at left) (HUS) - 33077 Complete Brake Assembly RH, Standard Wire (Red) (shown at left) 12.25" x 5", 7-Bolt, 12,000 lb Axle Capacity PART# DESCRIPTION (HUS) - 33078 Complete Brake Assembly LH, Standard Wire (Red) (HUS) - 33079 Complete Brake Assembly RH, Standard Wire (Red) (HUS)
21 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. ELECTRIC BRAKES Brake Assemblies CSA Compliant (HUS) RUGGED IS STANDARD EQUIPMENT.™ HUSKY® ELECTRIC BRAKE ASSEMBLY KITS FOR AXLE TEK, DEXTER, FAYETTE, HAYES & ALKO ELECTRIC BRAKES Save time and money by installing Husky Brake Assemblies. Why replace shoes, magnets, springs, adjusters, etc.? If you have to replace two or more of these components, it is easier and more economical to install the complete assembly. With Husky, you get back on the road fast! Reduce precious time and aggravation on difficult brake repairs by using Husky easy to install complete brake assembly kits. These CSA certified kits provide durability, and reliability in braking performance. These kits fit Axle Tek, Dexter, Fayette, and Hayes, with these flange patterns: 3” hole diameter x 4-holes x 4” bolt center on 7” and 10” brakes; 3.25” hole diameter x 5-holes x 3.88” bolt center on 12” brakes. All kits are individually boxed. HUSKY® HYDRAULIC BRAKE ASSEMBLY KITS FOR AXLE TEK, ATWOOD, ALKO, DEXTER HYDRAULIC BRAKES Easy installation and interchangeability are just two features that rate Husky Uni-servo hydraulic brake assemblies among the best in the industry. These assemblies interchange with most major brands of axles, without modifying the axle or mounting flange. These assemblies also interchange with Atwood, Axle Tek, and Dexter hydraulic brake assemblies. Hub Pattern: 3” x 4-holes on 10” brakes; 3.25” x 5-holes on 12” brakes. All kits are individually boxed. ELECTRIC BRAKE ASSEMBLY KITS 7" x 1.25", 600-2,200 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 30789 Complete Brake Assembly LH (HUS) - 30788 Complete Brake Assembly RH (shown at left) 10" x 2.25", 2,300-3,500 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 30793 Complete Brake Assembly LH (HUS) - 30794 Complete Brake Assembly RH 12" x 2", 4,000-6,000 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 30799 Complete Brake Assembly LH (HUS) - 30800 Complete Brake Assembly RH 12" x 2", 7,000 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 30797 Complete Brake Assembly LH (HUS) - 30798 Complete Brake Assembly RH HYDRAULIC BRAKE ASSEMBLY KITS 10" x 2.25", 3,500 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 30785 Complete Brake Assembly LH, Black Painted (HUS) - 30784 Complete Brake Assembly RH, Black painted 12" x 2", 6,000 lb Rated Axle Capacity PART# DESCRIPTION (HUS) - 30786 Complete Brake Assembly LH, Black Painted (shown at left) (HUS) - 30787 Complete Brake Assembly RH, Black painted Brakes manufactured by Axle Teknology for Husky are CSA Certified (CSA master contract #239634) (HUS) - 30788 (Front) (HUS) - 30788 (Back) (HUS) - 30786
22 Brake Assemblies See manufacturer’s catalog for more applications. Specifications are subject to change without notice. IDLER HUBS RUGGED IS STANDARD EQUIPMENT.™ (HUS) - 33080 (HUS) - 33082 (HUS) - 33087 (HUS) - 33091 2,000 lb IDLER HUBS 4-4.00; L44610/L44610; Black push-in studs PART# DESCRIPTION (HUS) - 33080 Idler Hub, 2,000 lb (shown at right) 5-4.50; L44610/L44610; Black push-in studs; Standard Flange (HUS) - 33081 Idler Hub, 2,000 lb 5-4.50; L44610/L44610; Black push-in studs; Large Flange (HUS) - 33082 Idler Hub Kit, 2,000 lb (shown at right) 3,500 lb IDLER HUBS 5-4.50; L68111/L44610; Black push-in studs PART# DESCRIPTION (HUS) - 33083 Idler Hub, 3,500 lb 5-4.75; L68111/L44610; Large Flange/Large Bride (HUS) - 33084 Idler Hub, 3,500 lb 5-5.00; L68111/L44610; Large Flange/Large Bride (HUS) - 33085 Idler Hub, 3,500 lb 5-5.50; L68111/L44610; Black push-in studs (HUS) - 33086 Idler Hub, 3,500 lb 6-5.50; L68111/L44610; Black push-in studs (HUS) - 33087 Idler Hub, 3,500 lb (shown at right) 6,000 lb & 7,000 lb IDLER HUBS 6-5.50; 25520/15245;1/2-20; Push-in studs PART# DESCRIPTION (HUS) - 33088 Idler Hub, 6,000 lb 6-5.50; 25520/15245;9/16-18; Push-in studs (HUS) - 33089 Idler Hub, 6,000 lb 8-6.50; 25520/14276;1/2-20; Push-in studs (HUS) - 33090 Idler Hub, 7,000 lb 8-6.50; 25520/14276; 9/16-18; Push-in studs (HUS) - 33091 Idler Hub, 7,000 lb (shown at right) HUSKY® IDLER HUBS FOR AXLE TEK OR DEXTER • Provides gripping area when the brake shoes are activated • Compatible with electric and hydraulic drum brakes • Zinc and paint blended coating for durability • Black paint finish • Corrosion resistant, zinc-finished pressed in studs • Limited 1 year warranty (HUS)
23 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. REPLACEMENT PARTS Brake Assemblies (HUS) RUGGED IS STANDARD EQUIPMENT.™ QUALITY REPLACEMENT PARTS AXLE TEK, DEXTER - 7" X 1.25" Electric Brakes Ref. Husky Part # Mfr./Axle Tek# Dexter # Description (HUS) - 30789 #KB7E-01 K23-047-00 Complete Brake Assembly LH (HUS) - 30788 #KB7E-02 K23-048-00 Complete Brake Assembly RH 1, 2 (HUS) - 30816 #KB7E-05 K71-045-00 Shoe/Lining Kit 3, 4, 5 (HUS) - 30817 #KB7E-06 K71-057-00 Magnet Kit 4, 6, 7, 8 (HUS) - 30824 #KBE-363-00 K71-363-00 Spring Kit 9 (HUS) - 30830 #KBE-321-00 5121 Retainer Clip Pkg/10 1 1 7 6 2 2 8 3 3 4 4 5 9 REPLACES CSA Compliant QUALITY REPLACEMENT PARTS AXLE TEK, DEXTER - 7" X 1.25" & 7" X 1.75" Hubs-Drums & Idler Hubs, Electric/Hydralic Ref. Husky Part # Mfr./Axle Tek# Dexter # Description 1 (HUS) - 95912 #DL150-20 Grease Seals, 1.5” ID, Sleeve of 20 2, 3 (HUS) - 30812 #L44649/10 K71-306-00 Bearing Cone & Cup L44610 / L44649 4 (HUS) - 30792 #KBD-54522-17 008-257-05 Hub-Drum 5-4.5” BC Elec. 1.25” REPLACES
